Generac 0J1073 Consolidated Wiring Harness for 2010 20kW Generators

Description

The Generac 0J1073 Consolidated Wiring Harness is a genuine OEM replacement for select 2010-era 20kW air-cooled home standby generators. It provides the electrical connections between the Nexus controller and compatible generator components, helping transmit operating commands, sensor information, and system signals.

This harness may be used in certain generators equipped with the Generac 0H6680D Nexus controller. However, compatibility depends on the generator model, serial number, original wiring configuration, and existing controller revision.

Product Features:

• Genuine Generac OEM replacement harness
• Part number: 0J1073
• Described by Generac as a 2010 20kW consolidated harness
• Designed for select air-cooled home standby generators
• Supports connections between the controller, engine sensors, and electrical components
• Manufactured with model-specific connectors and wire routing
• Condition: New

Product Information:

• Manufacturer: Generac
• Brand: Generac
• Part number: 0J1073
• Product type: Consolidated generator wiring harness
• Application: Select 2010-era 20kW generators
• Controller application: Select units using 0H6680D
• Quantity: 1 wiring harness

Package Includes:

• 1 Generac 0J1073 consolidated wiring harness

Not Included:

• 0H6680D Nexus controller
• Controller mounting hardware
• 0J2438 conversion jumper harness
• 0H6680DSRV controller replacement kit

Important Controller Information:

The 0J1073 is a complete consolidated generator harness, not the conversion jumper used to install an 0H6680D controller in a generator originally equipped with an 0H6680A or 0H6680B controller.

If replacing an A- or B-series Nexus controller with an 0H6680D, the appropriate 0J2438 conversion harness or complete 0H6680DSRV replacement kit may be required instead.

Installation Information:

Disconnect utility power, generator output, transfer-switch control power, the generator battery, and all other electrical sources before installation. Label the existing connections and compare every connector with the replacement harness before removal.

Route and secure the new harness according to the generator service manual, keeping wiring away from hot surfaces, moving components, sharp edges, and fuel-system parts. Installation by a qualified generator technician is strongly recommended.

Confirm compatibility using the generator model number, serial number, production date, existing harness number, and controller part number before ordering.
